EXO Settings Reference

This is the master list of every setting in the ZeroStick app, grouped by where it lives. Each entry gives the label you see in the app, its range, its default and what it does. For explanations and advice, follow the links to each topic's own page.

"Stored" in the Default column means the value comes from the config or from the EXO, not from a fixed factory value. Settings in groups marked config are saved per config. Settings marked app apply everywhere.

Device screen (config)

Open a config → Device. See App tour.

Setting	Where	Range / options	Default	What it does
Name	Device → •••	Text	Config name	Renames the config
Description	Device → •••	Text	Empty	A free note about the config
Colour	Device → ‹ swatch ›	7 listed colours, or any colour from the wheel	Config colour	The config's colour; also lights your controller's light bar
Connection Method	Device → Connection Method	PS5 (P5General), Xbox, PC	PS5	Which console the EXO plays on, and what it presents as
Update rate	Device	125, 250, 500, 1000 Hz	250 Hz	How often a fresh report goes to the console
What you play with	Device → Connection Method	Auto, Mouse + Keyboard, Controller, Joystick + Mouse	Auto	Your input type; decides which settings the app shows
Mouse DPI	Device	800, 1600, 3200 (recommended), 6400, 8000, 12000, or typed (100–32000, step 50)	Config value	Tells the EXO your mouse's DPI; warns below 3200
Measure it instead	Mouse DPI sheet	Start / Stop / Cancel	—	Works out your DPI from a known hand movement
Your mouse is set to	HOME → Check rate	125, 250, 500, 1000, 2000+ Hz, Not sure	Not sure	Compares your mouse's measured report rate with its setting
Adapter is sending inputs	Device	On / off	On	Kill switch: off stops the EXO sending anything, instantly
Calibration pack	Device	Installed packs, None	Current	Uses a game measurement someone has already made
Game	Device → game banner	Game list, or a game code	Current	Sets the config's game
Game preset	Device → Game Settings	Preset list	Picked	Applies a game's preset aim settings
Config photo	Device → camera key	JPEG, PNG, WebP	Monogram	Picture behind the config banner
PC identity	Device → Advanced → PC output	Identities listed by the EXO	Stored	Which controller the PC sees

Lighting (config)

Setting	Where	Range / options	Default	What it does
Controller light bar	Device → ••• → Light bar	Config colour, Own colour, Off	Config colour	What your controller's light shows
EXO light	Device → ••• → Light bar	Config colour, Own colour, Off	Config colour	What the EXO's own light shows
Own colour	Device → ••• → Light bar	Colour list	Config colour	Colour used when the mode is Own colour
Light bar mode	Light bar screen	One colour, Rainbow, Off	One colour	DualSense light bar effect
Brightness	Light bar screen	0–100 %	Stored	Light bar brightness
Rainbow speed	Light bar screen	1–100 % (Rainbow only)	Stored	How fast the rainbow cycles

Roles and Modifiers (config)

Setting	Where	Range / options	Default	What it does
Aim / ADS button	Roles	Any button	Stored	Which button counts as aiming (switches Hip and ADS settings)
Register at	Roles → Expert	0–50 %	2 %	How far a trigger must be pulled before it counts (ignored when a hair trigger is set)
Shift layer	Modifiers	Hold button + press button	None	Makes buttons do something else while a modifier is held
Button binding	Mappings	Any key or controller button, or none	Stored	What the button sends. "None" shows Not bound and sends nothing

Aim: mouse configs (config)

Full explanations: Aim settings.

Setting	Where	Range / options	Default	What it does
Speed (Hip)	Aim → Hip	0–100 (0 = Standard); cm/360 = 500 ÷ Speed	0	Hip mouse sensitivity
Speed (ADS)	Aim → ADS	0–100 (0 = Same as hip)	0	Mouse sensitivity while aiming
Fine aim	Aim → Hip / ADS	0–100 %, step 5	0 (ADS: hip value)	Makes small, slow moves count for more
Hip curve	Aim → Curve	2–16 handles (starts at 7); Linear, Ease-in, Ease-out, S-type	Straight line	Hand speed → turn speed
ADS curve	Aim → ADS → Curve	Same as hip, Even, Gentle, Aggressive	Same as hip	Curve while aiming
Smoothing preset	Aim → Smoothing	Disabled, Light, Balanced, Heavy, Synchronous (Classic), Custom; ADS adds Same as hip	Stored	Ready-made smoothing
Smoothing mode	Aim → Smoothing → Custom	Standard, Classic	Standard	Adaptive filter or XIM APEX style
Precision	Smoothing → Standard	0–100 %, step 0.5	0	Smoothing at low hand speed
Response	Smoothing → Standard	0–100 %, step 0.5	10 %	How fast the filter lets go on quick moves
Easing	Smoothing → Standard	0–100 %, step 0.5	35 %	Softer start from rest
Smooth	Smoothing → Classic	0–100, step 0.5	20	XIM APEX Smooth
Decay	Smoothing → Classic	0–20, step 0.5	9	XIM APEX Decay
Synch	Smoothing → Classic	0–64 ms	8 ms	Evens aim over this many ms
Y Scale	Aim → Mechanics	30–200 %, step 5	100 %	Vertical speed compared with horizontal
Invert	Aim → Mechanics	Off, Vertical, Horizontal, Both	Off	Flips mouse axes
Quantization: Magnitude	Aim → Mechanics	0–100 %, step 5	0	Rounds aim speed to steps
Quantization: Angle	Aim → Mechanics	0–100 %, step 5	0	Rounds aim direction to steps
Activate	Aim → ADS → Activation	0–1000 ms, step 4	0	Wait before ADS settings apply
Deactivate	Aim → ADS → Activation	0–1000 ms, step 4	0	Wait before hip settings return
Smooth ADS Transition	Aim → ADS → Activation	On / off	Off	Blends sensitivity across the wait
Ignore tiny movement	Aim → Advanced	0–50 counts	0	Ignores very small mouse motion
Feel	Aim → Advanced	Snappy, Balanced, Smooth	Snappy	How the aim stops when your hand stops
Start-up feel	Aim → Advanced	0–200 ms, step 5	0	Eases movement from rest

Aim: controller configs (config)

Setting	Where	Range / options	Default	What it does
Curve mode	Aim → Response Curve	Native, EXO Linear (calibrated games), Custom	Native	Game's curve, straightened, or your own
Curve preset	Aim → Response Curve	Snappy, Linear, Precise, Custom	Linear	Ready-made stick curve
Curve slider	Aim → Response Curve	0–200	Follows the curve	Bends the stick curve
Custom curve	Aim → Response Curve → editor	2–16 handles	Straight	Draw your own stick curve
Aiming curve (ADS)	Aim → ADS Curve	As above; "Use the hip curve while aiming" clears it	Hip curve	Separate curve while aiming
Invert Left/right, Up/down	Aim → Response Curve	On / off each	Off	Flips a stick axis
Inner deadzone	Aim → Deadzones	0–40 %	Stored	Ignores stick movement near centre
Outer deadzone	Aim → Deadzones	0–40 %	Stored	Reaches full output before the stick's edge
Anti-deadzone	Aim → Deadzones	0–40 %	0	Starts output past the game's own deadzone
Limit (stick)	Aim → Deadzones	10–100 %	100 %	Caps stick output
Deadzone shape	Aim → Deadzones	Round, Per-axis	Round	Deadzone geometry
Hair trigger L2 / R2	Aim → Trigger Settings	0–50 % (0 = Off)	Off	Full trigger once past this point
Limit (trigger)	Aim → Trigger Settings	10–100 %	100 %	Caps trigger output
Movement speed	Aim → Speed	10–100	100	Left-stick speed
Sensitivity	Aim → Speed	10–100	100	Aim-stick speed
Smoothing	Aim → Speed	Disabled, Light, Balanced, Heavy, Custom	Stored	Stick smoothing
Steadiness	Aim → Smoothing Custom	0–95 %, step 5	35 %	Custom stick smoothing strength
Same as hip	Aim → ADS	On / off	On	ADS uses the hip stick settings
ADS Sensitivity	Aim → ADS Speed	10–100	Hip value	Aim-stick speed while aiming
ADS smoothing	Aim → ADS Speed	Disabled, Light, Balanced, Heavy	Stored	Stick smoothing while aiming

Translation and keyboard movement (config)

Explained in How translation works.

Setting	Where	Range / options	Default	What it does
If a controller stick is plugged in too	Translation; Keyboard movement	Whichever is pushed further, Add them together	Whichever is pushed further	How a real stick and keys or mouse combine
Sync to game	Translation	Off, 60, 120 Hz	Off	Paces output to the game's stick rate
Use this game's translator / standard / restore previous	Translation	Buttons	Standard	Picks the measured aim model or the generic one
Smooth keyboard movement	Keyboard movement	On / off	On	Ramps WASD instead of jumping to full
Walk speed	Keyboard movement	0–100 %	55 %	Walk-key stick amount
Time to full run	Keyboard movement	0–600 ms	120 ms	Ramp-up time
Time to stop	Keyboard movement	0–400 ms	80 ms	Ramp-down time
Diagonal speed	Keyboard movement	Same as straight, Faster	Same as straight	Diagonal stick amount
Turn assist	Keyboard movement	0–100 %	0	Helps direction changes
Small movement boost	Keyboard movement	0–90 %	0	Anti-deadzone for keys

Behavior simulation (config)

Setting	Where	Range / options	Default	What it does
Script timing	Translation → Behavior simulation	0 ms up to the app's maximum	0	Random timing variation on scripts
Wait variation	Translation → Behavior simulation	0–50 %	0	Lengthens Smart Action waits by a random amount
Aim actions	Translation → Behavior simulation	0.5–10 %, step 0.5	Stored	How much each scripted stick push varies
Aim angle	Translation → Behavior simulation	0–15°, step 0.5	Stored	How far each scripted push may rotate
Left stick movement	Behavior simulation → analog	0–100 %	0	Analog variation on movement
Aiming stick keys	Behavior simulation → analog	0–100 %	0	Eases keys bound to the right stick
Right stick look	Behavior simulation → analog	0–100 %	0	Analog variation on look
Triggers	Behavior simulation → analog	0–100 %	0	Eases key-driven triggers

Calibration (config)

Setting	Where	Range / options	Default	What it does
Hip X / Hip Y / ADS X / ADS Y	Aim Speed Match	180–36000 ms per turn (shown as deg/s)	Measured	Measured turn speeds
Stick force	Aim Speed Match	Off, 10, 15, 20, 25, 30, 40, 55 %	Stored	Limits the stick while measuring
Game dead zone, Dead zone ADS, Stick while measuring, Full turns for X	Manual calibration	Steppers	From game data	Inputs for measuring by hand
In-game sensitivity it was measured at	Calibrate	Text	From pack	Records the in-game setting used
In-game dead zone	Calibrate	Text (optional)	From pack	Records the in-game deadzone
Game name / calibrated / who calibrated	Save as game pack	Text, on/off, text	Config name; off	Saves your measurement as a game pack

XIM import (config)

Setting	Where	Range / options	Default	What it does
Your XIM	Legacy Devices → Copy your XIM settings in	XIM MATRIX, XIM APEX, XIM NEXUS	Stored	Which XIM you're importing from
Sensitivity (hip / ADS)	XIM import	Number (cm/360)	—	Your XIM sensitivities
Y Scale	XIM import	Number	1.00	Your XIM Y ratio
Inner / Outer / Axial dead zone	XIM import	Number (%)	—	Your XIM deadzones
Settings inheritance	XIM import	Inherit All, Sensitivity Only, Inherit Nothing	Stored	How ADS inherits hip
Share code	XIM import	Text	Empty	Paste a XIM MATRIX share code

Smart Actions (config)

The main options for each Smart Action. Step-by-step fields are covered in Smart Actions and Script timing.

Setting	Where	Range / options	Default	What it does
Action switch	Scripts list	On / off	Stored	Turns one Smart Action on or off
Rapid fire Speed	Scripts list	2–33 taps/s	Stored	Turbo rate
Strength / Pull down	Scripts list	2–25 % / 3–60 %	Stored	Strength for aim and anti-recoil actions
How should this button behave?	Behaviour sheet	While I hold it, On then off, Only a quick tap, Only a long hold	While I hold it	How a plain remap behaves
A quick tap is under / Hold it for	Behaviour sheet	1–60000 ms, step 25	200 ms	Tap and long-hold threshold
When should this happen?	When sheet	When I press it, hold it down, tap it twice, Over and over while I hold it, Only while I hold it, and more	Stored	What starts the action and whether it repeats
Counts as held after	When sheet	100–2000 ms, step 50	Stored	Hold threshold
Taps must land within	When sheet	150–1000 ms, step 25	Stored	Double-tap window
Counts as quick under	When sheet	80–600 ms, step 10	Stored	Quick-tap limit
Human / Exact timing, Wobble by up to	Timing	0–500 ms, step 5	15 ms when Human	Random timing variation on steps
Stick variance	Timing	0–10 %	±1 %	Random variation on each stick push
Give up after	Safety	100–30000 ms, step 500	Stored	Hard stop for the action
Never give up	Safety	On / off	Off	Runs until stopped
Wait before it can fire again	Safety	0–60000 ms, step 50	Stored	Cooldown
How many times	Safety	1–10	Stored	Repeats per trigger
Always finish	Safety	On / off	Off	Finishes even if you let go
Shots per minute	Helpers	60–1400 rpm, step 10	600	Spaces waits to a fire rate

AI Scripts and Recoil Workshop (config)

Setting	Where	Range / options	Default	What it does
Weapon kind switch	AI Scripts	On / off	On	Turns recognition of a weapon type on or off for this config
Rarity chips	AI Scripts → weapon	Any, plus the pack's tiers	Any	Gives different scripts to different rarities
I've checked my game settings	Recoil Workshop → Check	On / off	Off	Must be on before tracing
Only while aiming down sights	Recoil Workshop	On / off	Stored	Correction only while aiming
Fire rate	Recoil Workshop → Fire rate	60–3000 RPM, step 10	Stored	The gun's fire rate
Rounds in the magazine	Recoil Workshop → Fire rate	2–100	Stored	Full magazine size
Shots landing on top of each other?	Recoil Workshop → Trace	Off, Small, Medium, Large	Off	Spread of overlapping marks
Test it with the gun	Recoil Workshop → Tune	On / off	Off	Runs the pattern while Fire is held
Fewer moves	Recoil Workshop → Tune	0–10	Stored	Merges small moves
Scale X / Scale Y	Recoil Workshop → Tune	0–400 %, step 5	100 %	Sideways / vertical correction
Wait scale	Recoil Workshop → Tune	25–400 %, step 5	100 %	Stretches the timing
Pull down	Recoil (controller)	0–100 %	Stored	Downward pull
Pull sideways	Recoil (controller)	−100 to 100 %	0	Sideways pull
Start delay	Recoil (controller)	0–2000 ms, step 10	Stored	Delay after firing starts
Start / Middle / End	Recoil (controller) → strength over mag	0–200 %, step 5	Stored	Strength through the magazine
Spray lasts	Recoil (controller) → strength over mag	0.5–10 s, step 0.5	Stored	How long a magazine lasts

See AI scripts and Recoil Workshop.

Screen Assist (config)

Setting	Where	Range / options	Default	What it does
Use aim help in this config	Screen Assist → Play	On / off	On	Aim help on or off
How much it helps	Play	0–100 %	35 %	Pull strength
How fast it snaps	Play	0–100 %	63 %	Pull speed
How it helps	Play	Gentle assist, Lock on	Gentle assist	Assist style
When it works	Play details	All the time, Only firing from the hip, Only while aiming, Only while shooting	Only while aiming	When aim help runs
Up and down reach	Play details	10–100 %	60 %	Vertical reach
Sightings before it locks	Play details	1–6 frames	2	Frames before a target counts
Colour tolerance	Play details	10–120	45	How closely a colour must match
How sure it must be	Trained model	10–90 %	35 %	Detection confidence
Aim the model at	Trained model	Head, Chest	Chest	Aim point
Fine tune up / down	Where it aims	0–50 (tenths of a marker)	0	Vertical offset
Fine tune left / right	Where it aims	−20 to 20 % of screen	0	Horizontal offset
How far it reaches	Reach & tracking	Nearby, Wide, Everywhere	—	Reach preset
Reach	Reach & tracking	2–150 % of screen	12 %	Reach radius
Leave alone when this close	Reach & tracking	0–50 % of screen	1 %	Stops moving near the target
How fast it moves your aim	Reach & tracking	1–100 %	20 %	Largest stick push it adds
How much it takes over	Reach & tracking	0–100 %	30 %	How its output is weighed against your own stick
Aim ahead of moving targets	Reach & tracking	0–300 ms	0	Leads moving targets
Ignore things bigger than	Reach & tracking	0.1–100 % of screen	25 %	Ignores large shapes
Take the shot at the green / Let go at the right moment	Shot assist	On / off	Off	Releases the button automatically
When it lets go	Shot assist	Stepper and slider (ms)	0	Release timing trim
Button to hold	Shot assist	Controller buttons	Stored	The button it releases
How sure before it acts	Shot assist	Strict, Normal, Loose	Normal	Certainty needed
Colour code / How close the colour has to be	Colour	Hex; Exact, Normal, Loose	—	Target colour and tolerance
Show the picture	Picture	On / off	Stored	Live preview on or off
How big to send it	Picture	Small 320, Normal 640, Large 1280 px	Normal	Preview size
Black and white	Picture	On / off	Off	Greyscale preview
What should your adapter do with it?	Area sheet	Search only here, Ignore, Watch for a colour, Watch it light up, Watch for movement, Read what it says, Read a number	Stored	What a drawn box is for

Legacy Devices and EXO Studio (device-wide)

Setting	Where	Range / options	Default	What it does
GPC script device	Legacy Devices	On / off (not with EXO Studio)	Off	Runs the config's GPC scripts on the EXO
Where the scripts run	GPC tab	Preview on phone, Live on Core	Preview	Test on the phone, or drive the EXO
Slots 1–8	GPC tab	8 slots	1	Picks the running memory slot
EXO Studio	EXO Studio room	On / off (not with GPC script device)	Off	Lets the EXO Studio PC app send to the EXO

Global Settings (app)

Setting	Where	Range / options	Default	What it does
Passthrough Mode	HOME; General	On / off	Off	Passes your real input straight through for menus
Shortcut buttons	General → Passthrough Mode	On / off	Stored	Lets the combos toggle Passthrough Mode
Your shortcuts	General	Pairs of 2 inputs; Restore defaults	EXO defaults	The Passthrough combos
Tournament Mode	General	On / off	Stored	Turns off scripts, Smart Actions, AI and aim help
Controller shortcut	General → Change config from controller	On / off	Stored	A button chord moves to the next config
Shortcut	General → Change config from controller	Home + Share/View, Home + L3	Home + Share/View	Which chord changes config
Menu light and buzz	General → Script menus	On / off	Off	Controller light and rumble respond to a script's menu
Theme	Appearance	Dark, Light, Match system	Dark	App theme
OLED black	Appearance	On / off	Off	True black in Dark
Show real units	Units	On / off	Off	Also shows cm/360 and deg/s
Show help buttons	Help	On / off	On	Shows the "?" help chips
Make everything easier to see	Access	Button	Off	Turns on the three settings below at once
Text size	Access	Default, Large, XL	Default	App text size
High contrast	Access	On / off	Off	Stronger text and borders
Reduce motion	Access	On / off	Off	No slide or fade animations
Bigger touch targets	Access	On / off	Off	Larger controls
Hold-repeat speed	Access	Fast, Normal, Slow	Normal	How fast steppers repeat when held
Wi-Fi network / password	HOME → WI-FI chip	Name up to 32 characters, password up to 63; 2.4 GHz only	—	Joins the EXO to your Wi-Fi
